Chapter 1: Cyclone III Device Datasheet
Electrical Characteristics
Schmitt Trigger Input
Cyclone III devices support Schmitt trigger input on TDI , TMS , TCK , nSTATUS , nCONFIG ,
nCE , CONF_DONE , and DCLK pins. A Schmitt trigger feature introduces hysteresis to the
input signal for improved noise immunity, especially for signal with slow edge rate.
Table 1–12 lists the hysteresis specifications across supported V CCIO range for Schmitt
trigger inputs in Cyclone III devices.
Table 1–12. Hysteresis Specifications for Schmitt Trigger Input in Cyclone III Devices
Symbol
V SCHMITT
Parameter
Hysteresis for Schmitt trigger
input
Conditions
V CCIO = 3.3 V
V CCIO = 2.5 V
V CCIO = 1.8 V
V CCIO = 1.5 V
Minimum
200
200
140
110
Typical
—
—
—
—
Maximum
—
—
—
—
Unit
mV
mV
mV
mV
I/O Standard Specifications
The following tables list input voltage sensitivities (V IH and V IL ), output voltage (V OH
and V OL ), and current drive characteristics (I OH and I OL ) for various I/O standards
supported by Cyclone III devices. Table 1–13 through Table 1–18 provide the I/O
standard specifications for Cyclone III devices.
Table 1–13. Cyclone III Devices Single-Ended I/O Standard Specifications
(1) , (2)
I/O Standard
Min
V CCIO (V)
Typ
Max
V IL (V)
Min Max
Min
V IH (V)
Max
V OL (V)
Max
V OH (V)
Min
I OL
(mA)
I OH
(mA)
3.3-V LVTTL
(3)
3.135
3.3
3.465
—
0.8
1.7
3.6
0.45
2.4
4
–4
3.3-V LVCMOS
(3)
3.135
3.3
3.465
—
0.8
1.7
3.6
0.2
V CCIO – 0.2
2
–2
3.0-V LVTTL
(3)
2.85
3.0
3.15
–0.3
0.8
1.7
V CCIO + 0.3
0.45
2.4
4
–4
3.0-V LVCMOS
(3)
2.85
3.0
3.15
–0.3
0.8
1.7
V CCIO + 0.3
0.2
V CCIO – 0.2
0.1
–0.1
2.5-V LVTTL and
LVCMOS (3)
1.8-V LVTTL and
LVCMOS
1.5-V LVCMOS
1.2-V LVCMOS
2.375
1.71
1.425
1.14
2.5
1.8
1.5
1.2
2.625
1.89
1.575
1.26
–0.3
–0.3
–0.3
–0.3
0.7
0.35 *
V CCIO
0.35 *
V CCIO
0.35 *
V CCIO
1.7
0.65 *
V CCIO
0.65 *
V CCIO
0.65 *
V CCIO
3.6
2.25
V CCIO + 0.3
V CCIO + 0.3
0.4
0.45
0.25 *
V CCIO
0.25 *
V CCIO
2.0
V CCIO –
0.45
0.75 *
V CCIO
0.75 *
V CCIO
1
2
2
2
–1
–2
–2
–2
3.0-V PCI
3.0-V PCI-X
2.85
2.85
3.0
3.0
3.15
3.15
—
—
0.3 *
V CCIO
0.35*
V CCIO
0.5 *
V CCIO
0.5 *
V CCIO
V CCIO + 0.3 0.1 * V CCIO
V CCIO + 0.3 0.1 * V CCIO
0.9 * V CCIO
0.9 * V CCIO
1.5
1.5
–0.5
–0.5
Notes to Table 1–13 :
(1) For voltage referenced receiver input waveform and explanation of terms used in Table 1–13 , refer to “Single-ended Voltage referenced I/O Standard”
in “Glossary” on page 1–27 .
(2) AC load CL = 10 pF.
(3) For more detail about interfacing Cyclone III devices with 3.3/3.0/2.5-V LVTTL/LVCMOS I/O standards, refer to AN 447: Interfacing Cyclone III
Devices with 3.3/3.0/2.5-V LVTTL and LVCMOS I/O Systems .
Cyclone III Device Handbook
Volume 2
July 2012 Altera Corporation
